Socket Weld Flange SW

A socket welding flange is a type of flange that is welded to a steel pipe at one end and connected by bolts at the other.

English Name: Socket Welding Flange

Sealing Face Types: Raised Face (RF), Male and Female Face (MFM), Tongue and Groove Face (TG), Ring Joint Face (RJ)

Materials:

Carbon Steel: ASTM A105, 20#, Q235, 16Mn, ASTM A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, ASTM A694 F42, F46, F48, F50, F52, F56, F60, F65, F70;

Stainless Steel: ASTM A182 F304, 304L, F316, 316L, 1Cr18Ni9Ti, 0Cr18Ni9Ti, 321, 18-8;

Alloy Steel: ASTM A182 F1, F5a, F9, F11, F12, F22, F91, A182 F12, A182 F11, 16MnR, Cr5Mo, 12Cr1MoV, 15CrMo, 12Cr2Mo1, A335 P22, St45.8/Ⅲ;

Manufacturing Standards: ANSI B16.5, HG20619-1997, GB/T9117.1-2000 to GB/T9117.4-2000, HG20597-1997

Connection Method: Flange nuts and bolted connection

Production Process: Professional integral forging, forging manufacturing, etc.

Processing Method: High-precision CNC lathe turning, precision turning on ordinary lathes, argon arc welding, etc.

Application Scope: Boilers and pressure vessels, petroleum, chemical industry, shipbuilding, pharmaceuticals, metallurgy, machinery, stamped elbows, food and other industries
